Key Features

- Imaging & Optics

• 1/2.9″ GC2053 CMOS sensor, delivers crisp 2 MP Full HD (1920×1080) video at 30 fps

• Dual-lens angle options:

  • Wide: 100° H × 57° V × 116° D

  • Standard: 80° H × 45° V × 92° D
    Ideal for choosing between broad situational awareness or focused reverse view.

• Low-light sensitivity down to 0.1 Lux, plus 12 IR LEDs for effective night vision.

- Durability & Environment

• IP69K rated enclosure — protects against high-pressure, high-temperature wash-downs

• Shock and vibration resistance up to 10 G — suitable for rugged vehicle or industrial use.

• Operating temperature: –20 °C to +70 °C (95% RH); Storage: –40 °C to +80 °C (95% RH).

- Physical & Mounting

• Compact dimensions: 94.5 × 60 × 81.5 mm; durable black metal or polymer housing.

• Surface-mount U-bracket, designed for reverse orientation (ideal for backup/side-view applications).

• Supplied hardware: 2 × M4×12 mm screws and hex key for secure angle adjustment.

- Connectivity & Power

• Analog PAL output, compatible with standard monitors/DVRs.

• 12 V DC input via 4-pin aviation connector, carrying power, video, and audio.

• Built-in microphone allows synchronized audio capture.

• 600 mm cable included to facilitate installation.

- Why This Camera Stands Out

• Versatile FOV options: choose wide panoramic view or zoomed-in angle based on needs.

• Reliable night operation thanks to IR LEDs and low-light sensitivity.

• Engineered for rugged conditions — IP69K and high vibration resilience.

• Easy integration: compact size, reverse-mount design, standard power/video interface
